1200 RPM Centre Shaft DC White Gearbox Motor
1200 RPM Centre Shaft DC White Gearbox Motor - Image 2
1200 RPM Centre Shaft DC White Gearbox Motor - Image 3

1200 RPM Centre Shaft DC White Gearbox Motor

Availability:

Out of stock
Compare

Specifications:

  • Operating Voltage : 12V
  • No-load current : 800mA
  • Load current : upto 7.5A(Max)
  • Base motor : 18000RPM
  • Shaft Diameter : 6 mm shaft with M3 thread hole
  • Gearbox diameter : 37mm
  • Motor Diameter : 28.5mm
  • Length : 63mm without shaft Shaft length : 30mm
  • Weight : 180gm
  • Torque : 4.5kgcm

₹18,054.00

Out of stock

Compare

1200 RPM Centre Shaft DC Gear Motor

1200 RPM 12V DC geared motors for robotics applications. Very easy to use and available in standard size. Nut and threads on shaft to easily connect and internal threaded shaft for easily connecting it to wheel.

RPM Torque
3 RPM 5.5 kg.cm
10 RPM 5 Kg.cm
30 RPM 4.5 kg.cm
60 RPM 3.5 kg.cm
100 RPM 3 kg.cm
200 RPM 2 Kg.cm
300 RPM 1.2 kg.cm
500 RPM 0.8 kg.cm
1000 RPM 0.5 kg.cm

Package Includes :

1 x 1200 RPM Centre Shaft DC White Gearbox Motor
