Panel Feed Through Terminal Block
2 Pin 20A 6.35mm Pitch Black Connectors for PCB Screw Terminal Block(Pack of 2 Pieces)
Specification:
- Manufacturer: JILN
- Package: Plugin, P=6.35mm
- Number of Positions/Pins: 1x2P
- Pin Location: Corner
- Barrier Type: Tri-Face
- Screw Specification: M2.5
- Rows/Pins Per Row: 1 Row, 2 Pins
- Pitch: 6.35mm
- Mounting Type: Straight Needle
- Operating Temperature: -40℃ to +105℃
- Current Rating: 20A
- Voltage Rating: 300V (Max)
- Colour: Black
- Part Number: CONN-TH JL635-63502B01
₹7,000.00
CompareThis 2-pin barrier terminal block features a 6.35mm pitch and a corner tri-face design, making it ideal for secure PCB connections. It supports up to 20A and 300V, ensuring reliable power transmission. The screw terminal design allows for easy wire connections, making it suitable for industrial and electronic applications.
Features:
- 2-pin barrier terminal block
- 6.35mm pitch for stable PCB mounting
- Rated for 20A, 300V
- Wide operating temperature: -40℃ to +105℃
- Secure screw terminal connection
- ROHS compliant
- Black plastic housing for durability
Package Include :
2 x 2 Pin 20A 6.35mm Pitch Black Connectors for PCB Screw Terminal
