LM7805 IC – 5V Positive Voltage Regulator IC
₹9.90 ₹49.00
7805 Voltage Regulator IC
The 7805 voltage regulator IC is a three-terminal voltage regulator IC. A 7805 voltage regulator with a fixed output voltage is used in various applications. This is available through various packages like SOT-223, TO-263, TO-220, and TO-3. Among these, the TO-220 is the most used one.
The IC 7805 is available in the TO220 package. It employs built-in current limiting, thermal shutdown, and safe operating area protection which makes them virtually immune to damage from output overloads.
7805 voltage regulator, although designed primarily as a fixed voltage regulator can also be used with external components for adjustable voltages and currents. With adequate heatsinking, they can deliver more than 0.5A output current.
read more: What is 7805 Voltage Regulator & Its Working
Features:
- Three-terminal positive voltage regulator IC
- Available in TO220 package
- Built-in current limiting, thermal shutdown, and safe operating area protection
- Primarily designed as a fixed voltage regulator
- It can be used for adjustable voltages and currents with external components
- Can deliver over 0.5A output current with adequate heatsinking
Know why the 7805 Voltage Regulator is essential in electronics.
Pinout:
Applications:
- Local (on-card) regulators
- IoT
Also, check the 7812 Voltage Regulator IC with an operating output voltage of 12V.
